REAR ARM
REAR ARM
Stator Unit Assy (Ref #1)
1
Part #5UY-W818A-10
. BEARING (Ref #2)
2
Part #93306-00523
. BEARING (Ref #3)
3
Part #93306-90505
. BUSH, REAR SHOCK ABSORBER (Ref #4)
4
Part #5UY-22216-00
Arm Sub-Comp. 2 (Ref #5)
5
Part #5UY-22140-01
BOLT,HEX.SOCKET HEAD (Ref #6)
6
Part #91317-06050
Washer, Plate (Ref #7)
7
Part #92907-06600
Pin, Dowel (Ref #8)
8
Part #99530-08012
BOLT,HEX.SOCKET HEAD (Ref #9)
9
Part #91317-08080
Washer, Plate (Ref #10)
10
Part #92907-08600
Pin, Dowel (Ref #11)
11
Part #99530-10114
Collar (Ref #12)
12
Part #90387-106J3
Cover, Gear (Ref #13)
13
Part #5UY-22371-00
Bearing (Ref #14)
14
Part #93306-90506
Bearing (Ref #14)
14
Part #93306-90506
Bearing (Ref #14)
14
Part #93306-90506
Bearing (Ref #14)
14
Part #93306-90506
Washer (Ref #15)
15
Part #5UY-22149-00
Circlip (Ref #16)
16
Part #99009-42500
Breather (Ref #17)
17
Part #3YJ-15371-00
Bolt, Flange (Ref #18)
18
Part #90105-06557
Bolt, Flange (Ref #19)
19
Part #90105-06042
Bolt, Flange (Small Head) (Ref #20)
20
Part #95024-06025
Pin, Dowel (Ref #21)
21
Part #93605-14143
Pin, Dowel (Ref #21)
21
Part #93605-14143
Pin, Dowel (Ref #21)
21
Part #93605-14143
Pin, Dowel (Ref #21)
21
Part #93605-14143
Gasket, Crankcase Cover 1 (Ref #22)
22
Part #5UY-15451-00
Cover, Thrust 1 (Ref #23)
23
Part #5UY-22128-00
Bolt, Flange (Ref #24)
24
Part #90105-10300
Nut, Self-Locking (Ref #25)
25
Part #95604-10200
Washer, Plate (Ref #26)
26
Part #90201-10013
Bracket 1 (Ref #27)
27
Part #3D2-2537W-00
Bolt, Hexagon Socket Head (Ref #28)
28
Part #91314-06012
HOSE (L198) (Ref #29)
29
Part #90445-11293
Clamp (Ref #30)
30
Part #90461-06001
Screw, Pan Head (Ref #31)
31
Part #98507-06012
