ELECTRICAL
ELECTRICAL
WIRE, MINUS LEAD (Ref #1)
1
Part #2DR-82116-00
Sensor, Air Temperature (Ref #2)
2
Part #5YU-85886-00
WIRE, SUB LEAD (Ref #3)
3
Part #1RC-82309-00
WIRE, SUB LEAD (Ref #4)
4
Part #1RC-82509-00
Battery Assy (Yuasa Ytz10S) (Ref #5)
5
Part #90793-26114
SPACER (Ref #6)
6
Part #1RC-8246K-00
STARTER RELAY ASSY (Ref #7)
7
Part #1RC-81940-00
Cover, Lead Wire (Ref #8)
8
Part #5SL-82119-30
Bolt, Flange (Ref #9)
9
Part #95022-06008
. FUSE (50A) (Ref #13)
13
Part #5JW-82151-10
. FUSE (2A-BL) (Ref #14)
14
Part #5JJ-82151-80
. FUSE (30A-BL) (Ref #15)
15
Part #5JJ-82151-60
CLAMP (Ref #16)
16
Part #1RC-82544-00
COVER, CONNECTER (Ref #17)
17
Part #1RC-82599-00
CLAMP (Ref #18)
18
Part #90464-15157
Rectifier & Regulator Assy (Ref #19)
19
Part #1D7-81960-01
Bolt, Flange (Ref #20)
20
Part #95022-06025
RELAY ASSY (5VK-40) (Ref #21)
21
Part #5VK-81950-40
RELAY ASSY (1ST-00) (Ref #22)
22
Part #1ST-81950-00
. HOLDER, RELAY (Ref #23)
23
Part #5JJ-81952-00
SENSOR, LEAN ANGLE (Ref #24)
24
Part #5PS-82576-01
BOLT (Ref #25)
25
Part #91312-04020
WASHER, PLATE (Ref #26)
26
Part #90201-04030
CLAMP (Ref #27)
27
Part #90464-13073
Clamp (Ref #28)
28
Part #90464-14010
BAND (Ref #29)
29
Part #3MA-82591-00
プロテクタ,ワイヤハーネス (Ref #30)
30
Part #1RC-82589-00
CLAMP (Ref #31)
31
Part #90464-16001
Rivet (Ref #32)
32
Part #90269-07015
. FUSE (10A-BL) (Ref #33)
33
Part #42X-82151-00
. FUSE (10A-BL) (Ref #33)
33
Part #42X-82151-00
. FUSE (10A-BL) (Ref #33)
33
Part #42X-82151-00
. FUSE (10A-BL) (Ref #33)
33
Part #42X-82151-00
