ELECTRICAL
ELECTRICAL
MAIN SW. IMMOBILIZER KIT (Ref #1)
1
Part #2S3-W8250-F0
. ENGINE CONTROL UNIT ASSY (Ref #2)
2
Part #2S3-8591A-40
. IMMOBILIZER. UNIT COMP. (Ref #3)
3
Part #2S3-8255P-00
. SCREW (Ref #4)
4
Part #5VU-82113-01
BLANK KEY (Ref #5)
5
Part #5SL-82511-08
BLANK KEY (Ref #6)
6
Part #2S3-82511-19
Wire, Sub Lead (Ref #8)
8
Part #2S3-82509-10
CLAMP (Ref #9)
9
Part #90464-25005
Wire, Sub Lead (Ref #10)
10
Part #2S3-82509-20
Neutral Switch Assy (Ref #11)
11
Part #2S3-82540-00
O-RING (Ref #12)
12
Part #93210-21001
Bolt, Hexagon Socket Head (Ref #13)
13
Part #90110-05053
OIL LEVEL GAUGE ASSY (Ref #14)
14
Part #2S3-85720-00
. O-RING (Ref #15)
15
Part #5VY-8A8E0-00
Bolt, Flange (Ref #16)
16
Part #95022-06016
CLAMP (Ref #17)
17
Part #2S3-85724-00
THROTTLE SENSOR ASSY (Ref #18)
18
Part #8CC-85790-01
Washer, Plate (Ref #19)
19
Part #90201-12172
Sensor, Air Temperature (Ref #20)
20
Part #5YU-85886-00
センサー,プレツシヤー (Ref #21)
21
Part #2C0-82380-00
Sensor, Cam Position (Ref #22)
22
Part #2S3-85896-01
. O-RING (Ref #23)
23
Part #4D9-81168-00
. BOLT, HEXAGON SOCKET HEAD (Ref #24)
24
Part #90110-06175
ステ-,メインスイツチ (Ref #25)
25
Part #2S3-82514-00
BOLT (Ref #26)
26
Part #90109-08207
DAMPER (Ref #27)
27
Part #2S3-28372-00
STAY (Ref #28)
28
Part #2S3-2117A-10
Nut, Spring (Ref #29)
29
Part #90183-06053
CAP, SWITCH (Ref #30)
30
Part #2S3-82552-20
. プレ-ト,マーク (Ref #31)
31
Part #2S3-8257H-20
DAMPER (Ref #32)
32
Part #2S3-8252R-10
Bolt, Button Head (Ref #33)
33
Part #92012-06012
HOSE (Ref #34)
34
Part #90445-07671
Band (Ref #35)
35
Part #12R-82591-00
Rivet (Ref #36)
36
Part #90269-05055
WASHER, PLATE (Ref #37)
37
Part #90201-067F9
Bolt,hex. Socket Button (Ref #38)
38
Part #90111-06007
HOLDER (Ref #39)
39
Part #2S3-84387-00
Bolt, Flange (Ref #40)
40
Part #95024-06012
HOLDER (Ref #41)
41
Part #2S3-8431U-00
Bracket, switch (Ref #43)
43
Part #2S3-27876-00
Bolt, Button Head (Ref #44)
44
Part #92014-05025
SWITCH, SIDE STAND (Ref #45)
45
Part #2S3-82566-00
Bolt, Button Head (Ref #46)
46
Part #92014-05020
Nut, U Flange (Ref #47)
47
Part #95604-05200
Nut, U Flange (Ref #47)
47
Part #95604-05200
Nut, U Flange (Ref #47)
47
Part #95604-05200
Nut, U Flange (Ref #47)
47
Part #95604-05200
Stop Switch Assy (Ref #48)
48
Part #2S3-82530-00
スイツチ,メ-タコントロ-ル (Ref #49)
49
Part #2S3-8358J-01
WHEEL SENSOR ASSY, FRONT (Ref #50)
50
Part #2S3-85970-00
Bolt, Button Head (Ref #51)
51
Part #92014-06014
WHEEL SENSOR ASSY, REAR (Ref #52)
52
Part #2S3-85980-00
GROMMET (Ref #54)
54
Part #2S3-14435-00
BAND (Ref #55)
55
Part #1UA-82591-00
