Front wheel/panel
Front wheel/panel
Shoe set, brake (Ref #1)
1
Part #06450-121-730
Shoe kit, brake (Ref #1)
1
Part #06450-178-932
Tube,tire (2.50-1 (Ref #2)
2
Part #42712-GS4-006
Tube2251250-17tr6 (Ref #2)
2
Part #42712-041-154
Flap,tire (Ref #3)
3
Part #42713-001-000
Flap,tire (Ref #3)
3
Part #42713-102-005
Axle e wheel (Ref #4)
4
Part #44301-GAC-000
Collar,wheel side (Ref #5)
5
Part #44311-041-000
Hub,wheel*nh-35m* (Ref #6)
6
Part #44601-GB4-000ZA
Collar,fr dist (Ref #7)
7
Part #44620-171-000
Rim,rr.wheel. (Ref #8)
8
Part #44701-102-792
Rim wheel (Ref #8)
8
Part #42701-102-793
Tire,fr. (Ref #9)
9
Part #44711-GB6-883
Tire,fr.(inoue) (Ref #9)
9
Part #44711-GB6-882
Cap,tire tube vlv (Ref #10)
10
Part #44717-041-000
Gear spdmt (Ref #11)
11
Part #44806-GK4-003
Шайба (Ref #12)
12
Part #44808-107-720
Sub comp.,*nh35m* (Ref #13)
13
Part #45010-GB4-306ZA
Pnl,brake*nh-35m* (Ref #13)
13
Part #45010-GK4-305ZA
Cam, rr. brake (Ref #15)
15
Part #43141-400-010
Spring, brake shoe (Ref #16)
16
Part #45133-028-000
Spring, brake shoe (Ref #16)
16
Part #45133-028-000
Spring, brake shoe (Ref #16)
16
Part #45133-028-000
Spring, brake shoe (Ref #16)
16
Part #45133-028-000
Dust seal, brake cam (Ref #17)
17
Part #45134-250-000
Indicator, fr. brake (Ref #18)
18
Part #45145-121-710
Arm,fr,brake (Ref #19)
19
Part #45410-GB4-000
Пружина (Ref #20)
20
Part #45411-GB4-680
Nut,rear axle (Ref #21)
21
Part #90305-041-000
Oil seal,21x35x7 (Ref #22)
22
Part #90752-GK4-003
Oil seal,21x35x7 (Ref #22)
22
Part #90752-GK4-005
Oil seal,47x60x7 (Ref #23)
23
Part #91251-GK4-005
Oil seal (47x60x7) (Ref #23)
23
Part #91251-GK4-003
Гайка (Ref #24)
24
Part #94050-06000
PIN (Ref #25)
25
Part #9420125300
Joint b, brake arm (Ref #26)
26
Part #9501532001
Nut b, brake rod adjusting (Ref #27)
27
Part #9501542000
Bolt, flange, 6x28 (Ref #28)
28
Part #95701-0602800
B/brg rad n/com (Ref #29)
29
Part #96140-630-001-0
B/brg rad n/com (Ref #29)
29
Part #96140-630-001-0
B/brg rad n/com (Ref #29)
29
Part #96140-630-001-0
B/brg rad n/com (Ref #29)
29
Part #96140-630-001-0
Spoke a 12x158.5 (Ref #30)
30
Part #97172-211-57F-0
Spoke a,12x158 (Ref #31)
31
Part #97548-211-56F-0
