Wire harness
Wire harness
Rod,tank open (Ref #1)
1
Part #17515-MZ1-000
Stopper,tank open (Ref #2)
2
Part #17516-MZ1-000
Rubber, spark unit (Ref #3)
3
Part #30405-MS2-000
Module, ign cont (Ref #4)
4
Part #30410-MZ1-671
Катушка зажигания (Ref #5)
5
Part #30510-KT7-023
Катушка зажигания (Ref #5)
5
Part #30510-KT7-023
Катушка зажигания (Ref #5)
5
Part #30510-KT7-023
Катушка зажигания (Ref #5)
5
Part #30510-KT7-023
Stay,ign coil (Ref #6)
6
Part #30515-MZ1-000
Кольцо/шайба (Ref #7)
7
Part #30520-ML7-000
Кольцо/шайба (Ref #7)
7
Part #30520-ML7-000
Кольцо/шайба (Ref #7)
7
Part #30520-ML7-000
Кольцо/шайба (Ref #7)
7
Part #30520-ML7-000
Cap assy,high/t 1 (Ref #8)
8
Part #30751-MZ1-000
Cap assy,high/t 2 (Ref #9)
9
Part #30752-MZ1-000
Cap assy,high/t 3 (Ref #10)
10
Part #30753-MZ1-000
Cap assy,hight/t (Ref #11)
11
Part #30754-MZ1-000
Rectifier, regulate (Ref #12)
12
Part #31600-MS2-601
Rectifier comp., silicon (Ref #13)
13
Part #31700-196-000
Wire harness (Ref #14)
14
Part #32100-MZ1-770
Wire harness (Ref #14)
14
Part #32100-MZ1-770
Wire harness (Ref #14)
14
Part #32100-MZ1-770
Wire harness (Ref #14)
14
Part #32100-MZ1-770
Clip, wire harness (Ref #15)
15
Part #32171-GJ1-003
Relay, turn signal (Ref #16)
16
Part #38301-KK9-952
Suspension, winker relay (mitsuba) (Ref #17)
17
Part #38306-KK4-000
Clip,flag pole (Ref #18)
18
Part #50323-HE0-671
Band.harness (Ref #19)
19
Part #90650-MA6-720
BAND (Ref #20)
20
Part #90651-MA6-720
BAND (Ref #20)
20
Part #90651-MA6-720
BAND (Ref #20)
20
Part #90651-MA6-720
BAND (Ref #20)
20
Part #90651-MA6-720
Clip, cable, 20mm (Ref #21)
21
Part #90690-GHB-661
Bolt, hex., 6x60 (Ref #22)
22
Part #92101-06060-4J
Гайка (Ref #23)
23
Part #94050-06000
Гайка (Ref #24)
24
Part #94050-06080
BOLT (Ref #25)
25
Part #95701-060-160-8
BOLT (Ref #26)
26
Part #96001-060-160-0
Fuse (Ref #27)
27
Part #98200-31000
Fuse (Ref #28)
28
Part #98200-31500
