Seat + rear spoiler (nss250s/nss250as)
Seat + rear spoiler (nss250s/nss250as)
Spring, governor (Ref #1)
1
Part #16561-ZE7-020
Switch assy (Ref #2)
2
Part #35400-SL4-013
COVER (Ref #3)
3
Part #35401-SL4-003
Болт (Ref #4)
4
Part #35409-692-013
Пружина (Ref #5)
5
Part #50513-GBL-000
Rubber, protector (Ref #6)
6
Part #64122-KPB-H00
Пружина (Ref #7)
7
Part #75581-GN8-920
Hinge assy., seat (Ref #8)
8
Part #77110-KSZ-770
Воздухопровод радиатора (Ref #9)
9
Part #77114-KPB-000
Seat, double (Ref #10)
10
Part #77200-KPB-000
Backrest assy. (Ref #11)
11
Part #77210-KPB-000
Catch, rr. seat (Ref #12)
12
Part #77220-KPB-010
Band, rubber (Ref #13)
13
Part #77227-KPB-000
Catch, seat (Ref #14)
14
Part #77230-KPB-000
Guide, seat catch (Ref #15)
15
Part #77238-KPB-000
Key, seat lock (Ref #16)
16
Part #77239-196-017
Cable a, seat open (Ref #17)
17
Part #77240-KPB-000
Cable b, seat open (Ref #18)
18
Part #77241-KPB-000
STAY (Ref #19)
19
Part #77244-KPB-000
Grip assy., rr. (Ref #20)
20
Part #77300-KPB-H01
Cap, r. rr. grip (Ref #21)
21
Part #77325-KPB-H01
Cap, l. rr. grip (Ref #22)
22
Part #77326-KPB-H01
Grommet, r. rr. grip (Ref #23)
23
Part #77327-KPB-H01
Grommet, l. rr. grip (Ref #24)
24
Part #77328-KPB-H01
Seat, back (Ref #25)
25
Part #77400-KPB-H01
Bolt (8x35) (Ref #26)
26
Part #90107-ME7-000
Bolt (8x35) (Ref #26)
26
Part #90107-ME7-000
Bolt (8x35) (Ref #26)
26
Part #90107-ME7-000
Bolt (8x35) (Ref #26)
26
Part #90107-ME7-000
Screw, pan (6x16) (Ref #27)
27
Part #90113-KPB-000
Nut, flange (self-lock) (m8x1.25) (Ref #29)
29
Part #90309-428-731
BOLT (Ref #31)
31
Part #95701-060-160-8
BOLT (Ref #31)
31
Part #95701-060-160-8
BOLT (Ref #31)
31
Part #95701-060-160-8
BOLT (Ref #31)
31
Part #95701-060-160-8
Bolt, flange, 8x20 (Ref #32)
32
Part #95701-080-200-0
