Фара
Фара
Rubber, radiator mounting (Ref #1)
1
Part #19051-KA3-830
COLLAR (Ref #2)
2
Part #19052-MAC-680
COLLAR, LED DRIVER (Ref #4)
4
Part #33104-MJT-E00
Led unit (Ref #5)
5
Part #33109-MJN-H01
Collar,tail light (Ref #6)
6
Part #33718-GAS-900
GROMMET (Ref #7)
7
Part #36037-657-000
Collar, rr. (Ref #8)
8
Part #50609-MFF-D00
Rubber, taillight (Ref #9)
9
Part #77209-MJM-D60
Bolt, flange (6x14) (Ref #10)
10
Part #90124-MJT-E00
BOLT, FLANGE (6X20) (Ref #11)
11
Part #90127-MJT-E00
BOLT, FLANGE (6X25) (Ref #12)
12
Part #90129-MJT-E00
BOLT, SOCKET (5X30) (Ref #13)
13
Part #90159-MJT-E00
Nut, clip (6mm) (Ref #14)
14
Part #90201-KPR-901
Washer, 6mm (Ref #15)
15
Part #90406-KV3-780
Гайка (Ref #16)
16
Part #94050-05070
Шайба (Ref #17)
17
Part #94101-05700
Шайба (Ref #18)
18
Part #94103-06700
HEADLIGHT ASSY. (Ref #19)
19
Part #33100-MJT-E01
