Масляный охладитель
Масляный охладитель
Cooler, oil (Ref #1)
1
Part #15600-MJT-E01
GRILL, OIL COOLER (Ref #2)
2
Part #15604-MJT-E00
CUSHION (Ref #3)
3
Part #15605-MJT-E00
STAY, O/CLR (LOWER) (Ref #4)
4
Part #15611-MJT-E00
PIPE, OIL COOLER IN. (Ref #5)
5
Part #15650-MJT-E00
Pipe (Ref #6)
6
Part #15660-MJT-E00
PLATE, OIL PIPE (Ref #7)
7
Part #15702-MJT-E00
Guide, cable (Ref #8)
8
Part #15711-MJT-E00
Nut, set (Ref #9)
9
Part #19014-KEA-003
Rubber, radiator mounting (Ref #10)
10
Part #19051-KA3-830
COLLAR (Ref #11)
11
Part #19052-MAC-680
Bolt (6x16) (Ref #12)
12
Part #90033-MJT-E00
Bolt, special (5x10) (Ref #13)
13
Part #90119-MGE-000
Bolt, flange (6x14) (Ref #14)
14
Part #90124-MJT-E00
BOLT, FLANGE (6X25) (Ref #15)
15
Part #90129-MJT-E00
Nut, spring, 5mm (Ref #16)
16
Part #90320-GE2-760
Прокладка (Ref #17)
17
Part #91314-MCF-000
Прокладка (Ref #18)
18
Part #91370-461-000
Гайка (Ref #19)
19
Part #94050-06080
BOLT (Ref #20)
20
Part #96001-060-200-0
