Рама
Рама
COLLAR (Ref #1)
1
Part #19343-MAL-600
Pin, kick starter (Ref #2)
2
Part #28321-427-770
Grommet, horn stay (Ref #3)
3
Part #38119-MM8-000
Frame *nh146m* (Ref #4)
4
Part #50100-MCS-L02ZA
Collar, fr. eng hgr (Ref #5)
5
Part #50190-MCS-G00
Collar, rr. engine (Ref #6)
6
Part #50191-MCS-G03
Collar, rr. eng hgr (Ref #7)
7
Part #50192-MCS-760
Collar, l. rr. (Ref #8)
8
Part #50193-MCS-G00
Collar, l. rr. (Ref #9)
9
Part #50195-MCS-000
Collar, fr. engine (Ref #10)
10
Part #50216-MCS-G02
Seat rail (Ref #11)
11
Part #50240-MCS-A30
Plate, r. fr. (Ref #12)
12
Part #50310-MCS-G00
Plate, l. fr. (Ref #13)
13
Part #50311-MCS-G00
Plate, rr. eng hgr (Ref #14)
14
Part #50312-MCS-G00
Plate, rr. eng hgr (Ref #15)
15
Part #50312-MCS-L00
Plate, r. stiffener (Ref #16)
16
Part #50315-MCS-A30
Plate, l. stiffener (Ref #17)
17
Part #50316-MCS-760
Plate, cross hanger (Ref #18)
18
Part #50318-MCS-760
Grip *nh105* (Ref #19)
19
Part #50400-MT3-000ZE
Spring, r (Ref #20)
20
Part #50617-MM5-000
Collar, handle setting (Ref #21)
21
Part #53103-GN5-900
Guard, r. engine (Ref #22)
22
Part #64206-MCS-A30
Guard, l. engine (Ref #23)
23
Part #64216-MCS-A30
Mat, r. frame (Ref #24)
24
Part #64324-MCS-G00
Mat a, heat guard (Ref #25)
25
Part #64363-MCS-G00
Mat b, heat guard (Ref #26)
26
Part #64364-MCS-G00
Mat c, heat guard (Ref #27)
27
Part #64365-MCS-G00
Mat, l. frame (Ref #28)
28
Part #64374-MCS-G00
Plate, r (Ref #29)
29
Part #77116-MCS-G00
Plate, l (Ref #30)
30
Part #77117-MCS-G00
Rubber, seat setting (Ref #31)
31
Part #77205-MCS-G00
Stay, amplifier (Ref #32)
32
Part #80150-MCS-A30
Bolt (10x328) (Ref #33)
33
Part #90102-MCS-G00
Болт (Ref #34)
34
Part #90112-MCS-G04
Bolt (8x30) (Ref #35)
35
Part #90131-MCS-760
Болт (Ref #36)
36
Part #90134-MCS-G01
Болт (Ref #37)
37
Part #90150-GN1-000
Nut, u, 10mm (Ref #38)
38
Part #90304-GE8-003
Washer, 10.5x27x4 (Ref #39)
39
Part #90405-758-L00
Шайба (Ref #40)
40
Part #90440-GT4-970
BAND (Ref #41)
41
Part #90679-SG9-E01
Clip, cable, 15mm (Ref #42)
42
Part #90690-GHB-651
Bolt-washer, 6x25 (Ref #43)
43
Part #93404-0602500
Гайка (Ref #44)
44
Part #94050-08000
Гайка (Ref #45)
45
Part #94050-10000
Washer, plain, 8mm (Ref #46)
46
Part #94102-08000
E-RING (Ref #47)
47
Part #94540-06018
Bolt, flange, 8x40 (Ref #48)
48
Part #95701-0804000
Болт (Ref #49)
49
Part #96300-0802000
Болт (Ref #50)
50
Part #96300-0802500
Болт (Ref #51)
51
Part #96300-0803500
BOLT (Ref #52)
52
Part #95701-080-400-8
Болт (Ref #53)
53
Part #96300-0805000
Болт (Ref #54)
54
Part #96300-1002500
Болт (Ref #55)
55
Part #96300-1005000
Болт (Ref #56)
56
Part #96400-1006500
